Milwaukee M18FMDP-0C M18 FUEL 18V Li-Ion Cordless Magnetic Core Drill – 38mm


ETA: 06/06/2022


Introducing the first Fuel Cordless Magnetic Drill, with its self powered magnet base helps delivery the industry’s strongest holding force on steel. The magnetic base operates without electicity, thanks to utilzing permanent magnets, ensuring the magnet doesn’t deactivate if the battery is drained. Power the the motor is automatically cut off if excess rotational motion is detected during drilling due to the auto-stop lift off detection.


  • 1 x FUEL® Hard Case
  • 1 x 3/4″ Weldon to 1/2″ Chuck adaptor
  • 1 x Chuck key
  • 1 x Magnetic lubrication tank
  • 1 x Safety strap
  • 1 x 1″ Retractable pilot pin


  • POWERSTATE™ brushless motor delivers maximum power and longer motor life
  • REDLINK PLUS™ intellegence provides optimised performance and overload protection
  • Self powered magnet base delivers up to 900 kg of holding force
  • 3/4″ Weldon to 1/2″ Chuck Adaptor
  • 38 mm Annular cutter capacity and 13mm twist bit capacity
  • 2 Speed gearbox (400 / 600 rpm)
  • Equiped with Auto-Stop lift off detection
  • On board cutting oil canister for customised applications
  • Built in LED light to illuminate the work surface
  • Drills 40 x 20 mm holes on 6 mm plate on one charge


  • Voltage: 18V
  • Speed: 400 / 600rpm
  • Holding Force: 900kg
  • Max Annular Cutting: 38mm
  • Max Twist Bit: 13mm
  • Minimum plate thickness: 6mm
  • Feed length:
    • Drill: 130mm
    • Tool: 146mm
  • LED light: Yes
  • Width: 355mm
  • Height: 395mm
  • Weight: 13.38kg
